Honed Cylinder Tube Features:
Type: Seamless, Hot Rolled, Cold Rolled, Cold Drawn
Straightness: ≤ 0.5/1000
Roughness: 0.2-0.4 u
Tolerance INT: H7,H8,H9
Hydraulic Cylinder Honed Tube
Honed Cylinder Tubing
Hydraulic Honed Tube
Pre-Honed Tubes
Standard Honed Tubes
Customized Honed Tubes
Honed cylinder tube processing principle:
1. The honed cylinder tube uses one or more whetstones installed on the circumference of the honing head, and the whetstone is expanded in the radial direction by an expansion mechanism (there are two types of rotation and push), so that it is pressed against the wall of the workpiece hole. In order to produce a certain surface contact. At the same time, the honing head rotates and reciprocates, and the parts do not move; or the honing head only rotates and the workpiece reciprocates, so as to realize honing.
2. In most cases, the honing head and the machine tool spindle or between the honing head and the workpiece fixture are floating. In this way, the honing head is guided by the hole wall of the workpiece during processing. Therefore, the machining accuracy is less affected by the accuracy of the machine tool itself, and the formation of the hole surface basically has the characteristics of the creation process. The so-called creation process is that the whetstone and the hole wall face each other and trim each other to form the hole wall and the whetstone surface. The principle is similar to the principle that two flat plates moving in a plane grind to each other to form a plane.
