Product Introduction
DALLAST is a high-tech enterprise specializing in the production of 3 stage hydraulic cylinder for dump truck actuators, hydraulic control systems and other automated hydraulic equipment. Since its establishment, DALLAST has always adhered to the management principle of talent-oriented and honest business.
DALLAST has strong technical strength, sophisticated equipment, advanced production technology and complete testing equipment. It has a group of experienced high-quality production technicians and has the ability to develop and develop new products. Dedication to provide quality and satisfactory service to our customers. Lifting force, stability is stronger, cylinder 27simn quenching and tempering treatment,
More resistant than ST52 / E355 / E460, strong pressure resistance, no deformation;
3 stage dump truck cylinder use sealing member has good sealing performance under the condition of -30°C-110°C, and it is not easy to leak oil. The cylinders of all levels have been treated with limit to avoid the hydraulic tipping rams falling off; it can meet the needs of customers more.
Model Description
① Level 4 stage
② Unit code
③ Pressure E: 160Bar /F210Bar
④ First stage size (mm)
⑤ Stroke (mm)
MODEL NO. | Stage | First Stage Diameter | Stroke | Largest Sleeve OD | Closed length | Mounting distance |
[mm] | [mm] | [mm] | [mm] | [mm] | ||
FC-3-110-2855 | 3 | 107 | 2855 | 152 | 1268 | 311 |
FC-3-110-3115 | 3 | 107 | 3115 | 152 | 1368 | 311 |
FC-3-110-3265 | 3 | 107 | 3265 | 152 | 1418 | 311 |
FC-3-110-3415 | 3 | 107 | 3415 | 152 | 1468 | 311 |
FC-3-110-3715 | 3 | 107 | 3715 | 152 | 1568 | 311 |
FC-3-129-3230 | 3 | 126 | 3230 | 219 | 1403 | 343 |
FC-3-129-3680 | 3 | 126 | 3680 | 219 | 1553 | 343 |
FC-3-129-3830 | 3 | 126 | 3830 | 219 | 1603 | 343 |
FC-3-129-4400 | 3 | 126 | 4400 | 219 | 1803 | 343 |
Market
Currently, DALLAST Technology 3 stage hydraulic cylinder for dump truck is already exported to Asia, Europe, South America, North America, Africa and Middle East and other regions.
For more details, please feel free to contact us. We will give you best service and timely reply.
Prodection detail
Product Process
Company Office
Deliver, shipping and serving
FAQ
Ukraine customers consulted with us about 3 stage hydraulic cylinder for dump truck
Q: Can You Give Me Help If My Products are Very Urgent?
A: Yes, Of Course, We Will Try Our Best to Give You Help. Because We Have Our Own Factory to Produce. We Can Flexible to Adjust Our Production Schedule.
Q: How can you ensure the 3 stage hydraulic cylinder for dump truck product quality?
A: Before shipment, all the 3 stage hydraulic cylinder for dump truck have Withstand Pressure test, ensure products can transportation safety and normal use.
Q: What are our after-Sales Services?
A: a). We are willing to improve the quality of the products if there is any problem with your order.
b). Repairs are free of charge if the problem is due to manufacturing defects.
c). We are willing to comply with customers' reasonable requests.
Q: How many hours is your piston rod resistant to salt spray?
A: The surface of our specially treated piston rod is black, the finish is RA<0.2 um, the tensile strength and yield strength are both greater than 900MPA, the surface hardness is HV 900, and the neutral salt spray test is 1100 hours; it is especially suitable for alkaline use. Environment, if you have any needs in this regard, please contact us.
If interesting our 3 stage telescopic hydraulic cylinder for dump truck and get more information, please contact our sales department, we are professional manufacturer of telescopic hydraulic cylinder for tipper truck.
